Inspection Plugs

Your system needs a new strategy,
Use Inspection Plug Strategies!

Features of Inspection Plug Strategies’ Plug:

No expensive installation tools required
No screws, "O" Rings, or silicone sealer needed
Does not rely on friction fit to keep rubber flange in place
No transition gasket required for corrugated metal
Makes a positive water tight seal

Follow these simple steps for Installation:

5 EASY STEPS TO INSTALL

Vector

Tml Inspection Port Silicone

IPS NDT Ports

The unique Patented System with Self-Sealing Flange and Cap is available in the following materials
50 Durometer EPDM Rubber:340 Degrees Temperature Resistance: -67F to +340F Tensile Strength: 2150 PSI Elongation: 420% UV and Ozone Resistance: EXCELLENT Meets ASTM D470 D624 D2137 D865 D395	50 Durometer Silicone Rubber: 500 Degrees Temperature Resistance: -130F to +500F Tensile Strength: 870 PSI Elongation: 250% UV and Ozone Resistance: EXCELLENT Meets ASTM D2000 SAE J200 GE507 E036 A19 B37
Descriptions
System II EPDM Sealing Flange, EPDM Cap, Stainless Steel attached lanyard. Color: Black Flange and Cap. TML Inspection Port EPDM One Piece: EPDM Sealing Flange, EPDM Cap Color: Black TMLX-SP EPDM EPDM Sealing Flange, EPDM Cap, Stainless Steel attached lanyard. Color:Black Flange and Cap Insertion depth: 10 MM	System V Silicone Sealing Flange, Silicone Cap, Stainless Steel attached lanyard. Color: Gray Flange and Cap. TML Inspection Port Silicone One Piece: Silicone Sealing Flange, Silicone Cap Color: Gray TMLX Inspection Port One Piece: Silicone Sealing Flange, Silicone Cap Color: Gray Depth: 10MM Fits thin Aerogel type insulation as well as all other types of thicker insulation. TMLX-SP Silicone Silicone Sealing Flange, Silicone Cap, Stainless Steel attached lanyard Color: Gray Flange and Cap Insertion depth: 10MM
Sizes Offered
System II and V Plug Sizes: 1.5", 2.5" 3 .5", 5" Outer Diameter (Size hole to cut): 1.5", 2.5" 3.5", 5.0" Inner Diameter (Size of test area): .5” less than outer diameter Insertion Depth: .75”	TML EPDM and Silicone Plug Sizes: 2.5", 3.0" TMLX Silicone Plug Sizes: 2.0", 3.0" TMLX-SP Plug Sizes: 3.5" X 12"

Download the Inspection Plugs Brochure

All Manufactured in the USA!
